Infini Solar V 4-TWIN

Customizable status LED ring with RGB lights

Infini solar V 4 TWIN is an upgraded version of the third generation of our Infini solar V. Equipped with a 4.3-inch color LCD, touchable button, and a customizable status LED ring with RGB lights. The high PV voltage range can be accepted, which will facilitate PV system installation. Besides, the battery independence feature will keep the inverter running whether the battery is connected or not. We also offer a parallel operation function up to 9 units for 3.6KW and 5.6KW. It provide high flexibility for future power expansion.

Main Features

  • Maximum PV input current 27A
  • Dual output for smart load management
  • Touchable button with large 4.3 colored LCD
  • Built-in Wi-Fi for mobile monitoring (APP is available)
  • Programmable supply priority for PV, Battery or Grid
  • User- adjustable charging current and voltage
  • Programmable multiple operation modes: Grid-tie, off-grid and grid-tie with backup
  • Reserved communication port for BMS
  • Parallel Operation up to 9 units
Category:

TECHNICAL SPECIFICATIONS
MODEL Infini Solar V 4 TWIN 6KW
Phase 1-Phase In / 1-Phase Out
Maximum PV Input Power 7000W
Rated Output Power 6000W
Maximum Charging Power 6000W
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage 360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage 120 VDC / 150 VDC
MPP Voltage Range 120 VDC – 430 VDC
Number of MPP Trackers / Maximum Input Current 1 / 27A
GRID OUTPUT (AC)
Nominal Output Voltage 220/230/240 VAC
Output Voltage Range 184 – 264.5 VAC or 195.5 – 253 VAC (Selectable)
Nominal Output Current 26A
Power Factor > 0.99
EFFICIENCY
Maximum Conversion Efficiency (DC / AC) 96%
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage / Auto Restart Voltage 120 – 140 VAC / 180 VAC
Acceptable Input Voltage Range 90 -280 VAC or 170 – 280 VAC
Maximum AC Input Current 40A
PV INPUT (DC)
Maximum DC Voltage 500 VDC
MPP Voltage Range 120 VDC – 430 VDC
Number of MPP Trackers / Maximum Input Current 1 / 27A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage 220/230/240 VAC
Output Waveform Pure Sine wave
Efficiency (DC to AC) 93%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage 360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage 120 VDC / 150 VDC
MPP Voltage Range 120 VDC – 430 VDC
Number of MPP Trackers / Maximum Input Current 1 / 27A
GRID OUTPUT (AC)
Nominal Output Voltage 220/230/240 VDC
Output Voltage Range 184 – 264.5 VAC or 195.5 – 253 VAC (Selectable)
Nominal Output Current 26A
AC INPUT
AC Start-up Voltage / Auto Restart Voltage 120 – 140 VAC / 180 VAC
Acceptable Input Voltage Range 90 -280 VAC or 170 – 280 VAC
Maximum AC Input Current 40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage 220/230/240 VAC
Efficiency (DC to AC) 93%
BATTERY & CHARGER
Nominal DC Voltage 48 VDC
Maximum Solar Charging Current 120A
Maximum AC Charging Current 120A
Maximum Charging Current 120A
GENERAL
PHYSICAL
Dimension D x W x H (mm) 140 x 295 x 468
Net Weight (kgs) 12
INTERFACE
Parallel Function Yes, 9 units
Communication Interface USB / RS232 / RS485 / WiFi / Dry-Contact
ENVIRONMENT
Humidity 0 – 90% Relative Humidity (Non-condensing)
Operating Temperature -10°C to 50°C
